Ankylosing spondylitis: investigation and management
Ankylosing spondylitis: investigation and management
Ankylosing spondylitis is a HLA-B27 associated spondyloarthropathy. It typically presents in males (sex ratio 3:1) aged 20-30 years old.Investigation
Inflammatory markers (ESR, CRP) are typically raised although normal levels do not exclude ankylosing spondylitis.
HLA-B27 is of little use in making the diagnosis as it is positive in:
- 90% of patients with ankylosing spondylitis
- 10% of normal patients
Plain x-ray of the sacroiliac joints is the most useful investigation in establishing the diagnosis. Radiographs may be normal early in disease, later changes include:
- sacroiliitis: subchondral erosions, sclerosis
- squaring of lumbar vertebrae
- 'bamboo spine' (late & uncommon)
- syndesmophytes: due to ossification of outer fibers of annulus fibrosus
- chest x-ray: apical fibrosis
If the x-ray is negative for sacroiliac joint involvement in ankylosing spondylitis but suspicion for AS remains high, the next step in the evaluation should be obtaining an MRI. Signs of early inflammation involving sacroiliac joints (bone marrow oedema) confirm the diagnosis of AS and prompt further treatment.
Spirometry may show a restrictive defect due to a combination of pulmonary fibrosis, kyphosis and ankylosis of the costovertebral joints.
40-year-old male. There is the typical appearance of bamboo spine with a single central radiodense line related to ossification of supraspinous and interspinous ligaments which is called dagger sign. Ankylosing is detectable in both sacroiliac joints- Image used on license from Radiopaedia
Ankylosing spondylitis with well-formed syndesmophytes- Image used on license from Radiopaedia
Lateral cervical spine. Complete fusion of anterior and posterior elements in ankylosing spondylitis, so called bamboo spine- Image used on license from Radiopaedia
Fusion of bilateral sacroiliac joints. Sacroiliitis may present as sclerosis of joint margins which can be asymmetrical at early stage of disease, but is bilateral and symmetrical in late disease- Image used on license from Radiopaedia
Syndesmophytes and squaring of vertebral bodies. Squaring of anterior vertebral margins is due to osteitis of anterior corners. Syndesmophytes are due to ossification of outer fibres of annulus fibrosus- e Image used on license from Radiopaedia
Lumbar spine x-ray of ankylosing spondylitis. Symmetric syndesmophytes of the lumbar spine. Some erosion of SI joints - Image used on license from Radiopaedia
Management
The following is partly based on the 2010 EULAR guidelines (please see the link for more details):
- encourage regular exercise such as swimming
- NSAIDs are the first-line treatment
- physiotherapy
- the disease-modifying drugs which are used to treat rheumatoid arthritis (such as sulphasalazine) are only really useful if there is peripheral joint involvement
- the 2010 EULAR guidelines suggest: 'Anti-TNF therapy should be given to patients with persistently high disease activity despite conventional treatments'
- research is ongoing to see whether anti-TNF therapies such as etanercept and adalimumab should be used earlier in the course of the disease
